The Uni-T MSO7104X is a nine-in-one powerhouse, combining a 1GHz, 4-channel digital oscilloscope with a logic analyzer, function/arbitrary waveform generator, spectrum analyzer, digital voltmeter, high-precision frequency counter, protocol analyzer, jitter/eye analyzer, and power analyzer—all backed by up to 5 years of warranty.
Experience the X-Factor with this multi-function instrument, designed to be the high-performance centerpiece of your test bench. The Uni-T MSO7104X is a versatile 1GHz, 4-channel oscilloscope that expands to include a spectrum analyzer, digital voltmeter, 7-digit frequency counter, and a serial bus protocol analyzer (RS232/RS422/RS485/UART, I2C, SPI, CAN, and LIN). Featuring 12-bit Enhanced Resolution (ERES), it offers exceptional signal clarity.
With Uni-T's UltraAcq® technology, the waveform capture rate reaches up to 800,000 wfms/s and 2,000,000 wfms/s in Sequence mode. The spectrum analyzer covers frequencies from 0Hz to 1.25GHz with up to 1Mpts enhanced FFT, and includes waterfall curves, multiple traces, and detection options. The digital voltmeter measures DC/AC RMS with precision and has limit alarms for threshold crossings. The built-in high-precision frequency counter offers 8-digit resolution and adjustable refresh times.
The Ultra Phosphor 3.0 display on a 15.6" FHD touchscreen enhances signal visibility, while multi-window functionality allows up to 4 independent time bases. The instrument supports 48 measurements, with 35 displayed simultaneously, and features advanced mathematical calculations, digital filters, and custom function definitions.
For digital signal analysis, add the MSO7104X-LA software and pair with Uni-T UT-M15 logic probes for 16-channel analysis. Unlock additional capabilities with options for a dual-channel, 60MHz function generator, jitter/eye analysis, power analysis, and extended bus triggering and decoding.
The Autoset function and enhanced memory depth streamline signal detection and analysis. It supports SCPI protocols, Python, and LabView, and includes a built-in web server for remote operation. The intuitive 15.6-inch multi-touch interface offers customizable user settings, and bandwidth upgrades are available. Connectivity options include USB 3.0, LAN, AUX, and HDMI, with certifications including cETLus, CE, ROHS, and UKCA.
UNI-T MSO7104X 1GHz 4Ch Mixed Signal Oscilloscope
1 GHz Bw, 4+16 CH, MSO ready, Max. 10 GSa/s, Memory depth: 1 Gpts, 2,000,000 wfm/s, 15.6" FHD Display
Optional Accessories:
Passive Probes:
UT-P03 Scope Probe
Passive Probe, Probe Attenuation: 10:1, Bandwidth (MHz): 60MHz, Voltage: 600VppUT-P04 Scope Probe
Passive Probe, Probe Attenuation: 10:1, Bandwidth (MHz): 100MHz, Voltage: 600VppUT-P05 Scope Probe
Passive Probe, Probe Attenuation: 10:1, Bandwidth (MHz): 200MHz, Voltage: 600VppUT-P06 Scope Probe
Passive Probe, Probe Attenuation: 10:1, Bandwidth (MHz): 300MHz, Voltage: 600VppUT-P07 Scope Probe
Passive Probe, Probe Attenuation: 10:1, Bandwidth (MHz): 500MHz, Voltage: 600VppUT-P08A Scope Probe
Passive Probe, Probe Attenuation: 10:1, Bandwidth (MHz): 350Mhz, Voltage: 600VppUT-P20 High Voltage Scope Probe
Passive Probe, Probe Attenuation: 100:1, Bandwidth (MHz): 250MHz, Voltage: 1500VppUT-P21 High Voltage Scope Probe
Probe Attenuation: 1000:1, Bandwidth (MHz): 50MHz, Voltage: DC 15kVrms/AC 10kVUT-V23 High Voltage Scope Probe
Passive Probe, Probe Attenuation: 100:1, Bandwidth (MHz): 100MHz, Voltage: 2000VppCurrent Probes:
UT-P40 AC/DC Current Probe
Voltage: 600Vrms, Output: 50mV/A, 5mV/A, Max A AC: N/A, MAX A DC: 60A, Frequency: DC~100kHzUT-P41 AC/DC Current Probe
Voltage: , Output: 100mV/A, 10mV/A, Max A AC: N/A, MAX A DC: 100A, Frequency: DC~100kHzUT-P42 AC/DC Scope Probe
Voltage: , Output: , Max A AC: , MAX A DC: 200A, Frequency: 150KHzUT-P43 Current Probe
Output: 100mV/A, Max A AC: 20A, MAX A DC: 20A, Frequency: DC~25MHzUT-P44 Current Probe
Output: 50mV/A, Max A AC: 40A, MAX A DC: 40A, Frequency: DC~50MHzDifferential Probes:
UT-P30 Differential Scope Probe
Differential Probe, Probe Attenuation: 10:1/100:1, Bandwidth (MHz): 100MHz, Voltage: ±800VppUT-P31 Differential Scope Probe
Differential Probe, Probe Attenuation: 10:1/100:1, Bandwidth (MHz): 100MHz, Voltage: ±1500VppUT-P32 Differential Scope Probe
Differential Probe, Probe Attenuation: 100:1/1000:1, Bandwidth (MHz): 50MHz, Voltage: ±3000VppUT-P33 Differential Scope Probe
Differential Probe, Probe Attenuation: 10:1/100:1, Bandwidth (MHz): 120MHz, Voltage: ±14KVppUT-P35 Differential Scope Probe
Differential Probe, Probe Attenuation: 50:1/500:1, Bandwidth (MHz): 50MHz, Voltage: 130VDC+PeakAC/1300VDCUT-P36 Differential Scope Probe
Differential Probe, Probe Attenuation: 200:1/500:1, Bandwidth (MHz): 100MHz, Voltage: 560VDC+PeakAC/5600VDCOther Accessories:
UT-ISOT Isolation Transformer
Used for Bode Plot analysis. Requires scopes to have MSO2000-S-BODE or MSO3000CS-S-BODE optionUT-M15 Logic Pod
16Ch Logic Analyzer Probe Pod for MSO and UPO Series mixed-signal oscilloscopesBAG-B3 Carry Bag
Taking your Uni-Trend Spectrum Analyzer and Digital Oscilloscope out into the field? Carry it safely from location to location with our padded carry bag.Oscilloscope Options
MSO7000X-AERO Aerospace serial bus trigger and analysis (MIL-STD-1553, ARINC 429) MSO7000X-AUDIO Audio serial bus trigger and analysis (I2S, LJ, RJ, TDM) MSO7000X-AWG Dual channel 60 MHz function/arbitrary waveform generator MSO7000X-BND Upgrade suite (JITTER, PWR, CANFD, FLEX, SENT, AUDIO, AERO) MSO7000X-BW-10T20 Bandwidth Upgrade from 1 GHz to 2 GHz for MSO7104X MSO7000X-CANFD Automotive serial bus trigger and analysis (CAN FD) MSO7000X-FLEX Automotive serial bus trigger and analysis (FlexRay) MSO7000X-JITTER Advanced Jitter analysis and Eye diagram MSO7000X-LA 16-channel logic analyzer MSO7000X-PWR Advanced power analysis MSO7000X-SENT Automotive sensor trigger and analysis (SENT)
