Metrel MI 3365 OmegaEE XD Electrical Equipment Tester Machine Switchboard Safety

• Visual inspections;
• Continuity // Protective earth resistance 200mA;
• Continuity // Protective earth resistance 10A, 25A;1
• Insulation Resistance (Riso, Riso-S);
• Protective conductor current (Direct, Residual, Alternative);
• Touch leakage current (Direct, Alternative);
• Leakage current produced by a floating input, PE current (Direct, Residual);
• Leakage current produced by a floating input, Touch current (Direct);
• Leaks & Power (Itou, Idiff, P, S, Q, PF, THDu, THDi, CosØ, I, U);
• Power (P, S, Q, PF, THDu, THDi, CosØ, I, U);
• PRCD test, (2 pole, 3 pole, K/ Di (varistor), S (3-pole));
• PRCD test (PE conductor, Open conductor, PE probe);
• RCD test (type A, AC, B, B+, F);
• IC-CPD test (EV-RCD, PE conductor);
• Voltage, SELV/PELV;
• Flash test, (1500V, 3000V);2
• Polarity / Active polarity test;
• EVSE Diagnostic test;
• Fuse test;
• Clamp current;3
• Functional inspections.

1(25A, M, F, models only),2(MI 3365 F model only), 3(With optional A 1283)

• Pre-defined AUTOSEQUENCE®s, according to: EN 50678, EN 50699, EV-Cables, P-RCDs, Floating inputs, EN 62368-1, EN 60974-4, EN 62353.
• Read the code and test: QR and barcode system of labelling in combination with AUTOSEQUENCE®s enables the user quick and simple testing of electrical devices.
• Testing groups: the instruments have built-in filters in accordance with their area of application, which enables the user simple choice of needed test sequences.
• Support for IC-CPD testing: support for testing Mode 2 and Mode 3 EV cables in combination with supported adapters.
• Support for PRCD testing: support for all types of PRCDs, including 2-pole, 3-pole, K/Di (varistor), S (3 pole) and testing with the PE probe.
• Fuse testing: the instrument has a special, integrated testing module for quick testing of all types of fuses.
• High-voltage testing (only MI 3365 F): the instrument enables insulation resistance measurement that has to be performed after repairs or maintenance of electrical devices.
• Testing of medical devices (only MI 3365 M): the instrument enables testing of medical devices in accordance with IEC/EN 62353 extended to tests in acc. with IEC 60601.
• Simulation of Single fault conditions enables testing of Audio/video, information and communication technology equipment IEC/EN 62368.
• Testing of welding equipment (only in combination with A 1422): all models of OmegaEE XD support testing of welding equipment in accordance with IEC/EN 60974-4.
• Hard-wired devices: the instruments have integrated additional test terminals that enable the user simple testing of hard-wired devices.
• Large memory: support for microSD memory cards, 8 GB card already integrated in the instrument, although that can be expanded to 32 GB.
• PC SW Metrel ES Manager: enables creation of test structures, user-defined AUTOSEQUENCE®s, professional test reports and data transfer for archiving.
• Touch screen: high resolution colour touch screen, 4.3” TFT.
• Double manipulation: keyboard and touch screen enable the user to control the instrument in any manner they like.
• aMESM Android SW: enables QR code scanning, and uploading of pre-prepared user-defined AUTOSEQUENCE®s.
