Metrel MI 2885 Master Q4, TRMS, VFD, Energy, Harmonic/Interharmonic Measure ST

• Instrument Master Q4
• Test probe, (brown, black, grey, green, blue), 5 pcs
• Crocodile clip, (brown, black, grey, green, blue), 5 pcs
• Voltage measurement lead, (brown, black, grey, green, blue), 5 pcs
• Labels for color coding
• MicroSD memory card 8.0GB
• MicroSD card reader
• PC SW PowerView3
• RS232, USB and Ethernet patch cable
• Power supply adapter
• 1.2 V NiMH rechargeable battery, 6 pcs
• Soft carrying bag
• Instruction manual
• Calibration certificate

Measuring functions

• Voltage: TRMS, peak, crest factor (4-channels);
• Current: TRMS, peak, crest factor (4-channels);
• Power (active, reactive, apparent);
• Power measurements fully compliant with IEEE 1459 (active, non active, fundamen­tal, harmonic, load unbalance);
• VFD (variable frequency drives);
• Unbalance, flicker measurement;
• Harmonic and interharmonic analysis up to 50th harmonics, THD measurement;
• Energy (active, reactive, generated, consumed);
• Capturing and recording of power supply events (shutdowns, interruptions, swells, dips);
• Inrush currents monitoring and recording;
• Waveform/inrush displaying, snapshot and recording;
• Power quality analysis according to EN 50160;
• Recording up to 7 adjustable alarms;
• Temperature measurement;
• Photo-voltaic inverter efficiency measurements;
• Power factor, cos φ.

Key features

• 4-voltage channels with wide measurement range: 0 ... 1000 Vrms (CAT III / 1000 V);
• 4-current channels with support for automatic clamp recognition and “on instrument“ range selection;
• Automatic Smart Clamp detection and Smart Clamp range selection;
• Compliance with power quality standard IEC 61000-4-30 Class S (0.1%);
• Complete power quality analysis according to EN 50160 including signalling and interharmonics;
• Support for microSD memory card (8-GB supplied with the instrument) up to 32 GB;
• Color-coded input terminals and termi­nal labels to suit your application region;
• Intuitive main menu and large icons that makes the equipment very easy to navigate and configure;
• Current clamp auto range selection;
• Powerful PC SW PowerView3 enables downloading, view, analysis of recorded data and professional report creation;
• Flexible clamps (without additional power supply) are included in the Euro set;
• Remote communication via Ethernet (GPS clock synchronization - optional).

MI 2885 Series
