The CC-TEV Capacitive Coupler detects TEVs as they pass over the cladding of the high voltage plant. Fast output signals are recorded by the ASM, PrecisePD or PD-SG1 systems. The sensor is encased in a durable PVC sleeve for added protection. Embedded in the body are powerful magnets allowing for coupling to steel enclosures.
Partial discharge activity inside metal clad high voltage plant induces small voltage impulses called Transient Earth Voltages on the surface of the metal cladding. These TEVs travel around the cladding surface to the outside of the gear, where they can be pick up using capacitive coupled transducers.
IPEC CC-TEV Capacitive Coupler Partial Discharge Sensor
Frequency Response 1MHz – 80MHz Dimensions
78 x 64 x 27mm
Rec. Load Impedance 50 Ω Output Connector
BNC Female
Weight
134g
Coupling
Magnetic Product only available in USA and Canada.
Please allow 30 day lead time for new product to arrive.
Comes with 12 month (One Year Warranty)
