Double polarized wideband horn antenna
The double polarized quad-ridged horn antennas of the PowerLOG® PRO series are characterized by enormous broadband performance and very high transmission power.
The gain increases with higher frequency up to max. approx. 12 dBi and generates a constant field strength, quasi-independent of the frequency. This predestines the PowerLOG® PRO 30600 especially for EMI compliance tests, since the amplifier does not have to be readjusted depending on the frequency. This saves a considerable amount of calibration and measurement effort.
Another special feature of the PowerLOG® PRO 30600 is its two inputs. This allows a horizontally or a vertically polarized measurement to be made without the need for an error-prone reconfiguration of the antenna. The PowerLOG® 30600 is suitable for both sending and receiving purposes. Due to the very high maximum transmit power of up to 500 W, the PowerLOG® is particularly suitable for EMC or interference emission measurements. The antenna is supplied incl. comprehensive, specific calibration data.
Highlights:
• Wide frequency range from 300 MHz - 6 GHz
• Supports very high power levels up to 500W (CW)
• Constant field strength due to linear increasing gain
• High gain up to 12 dBi
• Horizontal and vertical measurement without rebuild
• Delivery includes specific calibration data
• Perfectly suited for EMC measurements with spectrum analyzers
• Dimensions: 510 x 507 x 507 mm
• Weight: 8.8 kg
Aaronia PowerLOG PRO 30600 EMI Double Pole Broadband Horn Antenna 300MHz-6GHz
Frequency Range 300 MHz - 6 GHz Design Quad-ridged Active No Gain (max.) 12 dBi Connector 2x N (f) Mount Mounting bracket Dimensions 510x507x507 mm Weight 8.8 kg
